Residential Batteries

T-BAT-SYS-LV D53

5.3 kWh-85.1 kWh

SolaX T-BAT-SYS-LV D53 là hệ thống lưu trữ năng lượng dân dụng thế hệ mới, với công nghệ pin LFP tân tiến. Với dải dung lượng rộng từ 5.3kWh đến 85.1kWh và hỗ trợ song song tối đa 16 đơn vị, thiết bị này có khả năng lưu trữ linh hoạt, dễ mở rộng, đáp ứng nhu cầu sử dụng của gia đình hiện đại.

Xem video
Tải dữ liệu

Product Advantage

T-BAT-SYS-LV D53 nổi trội với hiệu suất cao, hỗ trợ dòng xả cực đại lên đến 200A và tuổi thọ hơn 6000 chu kỳ. Vỏ bảo vệ chuẩn IP65 cùng bộ vi xử lý hiệu năng cao đảm bảo vận hành ổn định trong nhiều điều kiện khác nhau. Thuật toán quản lý bằng AI và khả năng giám sát từ xa giúp kiểm soát năng lượng thông minh với mức bảo trì tối thiểu.

Assured Reliability

LiFePO4 battery cell & high-performance processors
IP65 protection degree

Flexible Adaptability

Floor or wall mounting optional
Modular design, expandable to 16 units in parallel

High Performance

Peak discharge current: 200A for 10s
Cycle life > 6000 times

Smart Management

Remote fault diagnosis, upgrade and maintenance
Al-driven intelligent algorithms for high SOC and accuracy

Product Parameters

T-BAT LD53
T-BAT LD106
T-BAT LD159
T-BAT LD212
T-BAT LD265
T-BAT LD318
T-BAT LD371
T-BAT LD424
T-BAT LD477
T-BAT LD530
T-BAT LD583
T-BAT LD636
T-BAT LD689
T-BAT LD742
T-BAT LD795
T-BAT LD848

T-BAT LD53
- SYSTEM DATA

  Number of modules 1
  Nominal capacity 5.3 kWh
  Max.output current 100 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD106
- SYSTEM DATA

  Number of modules 2
  Nominal capacity 10.6 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD159
- SYSTEM DATA

  Number of modules 3
  Nominal capacity 15.9 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD212
- SYSTEM DATA

  Number of modules 4
  Nominal capacity 21.2 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD265
- SYSTEM DATA

  Number of modules 5
  Nominal capacity 26.6 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD318
- SYSTEM DATA

  Number of modules 6
  Nominal capacity 31.9 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD371
- SYSTEM DATA

  Number of modules 7
  Nominal capacity 37.2 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD424
- SYSTEM DATA

  Number of modules 8
  Nominal capacity 42.5 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD477
- SYSTEM DATA

  Number of modules 9
  Nominal capacity 47.9 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD530
- SYSTEM DATA

  Number of modules 10
  Nominal capacity 53.2 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD583
- SYSTEM DATA

  Number of modules 11
  Nominal capacity 58.5 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD636
- SYSTEM DATA

  Number of modules 12
  Nominal capacity 63.8 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD689
- SYSTEM DATA

  Number of modules 13
  Nominal capacity 69.2 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD742
- SYSTEM DATA

  Number of modules 14
  Nominal capacity 74.5 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD795
- SYSTEM DATA

  Number of modules 15
  Nominal capacity 79.8 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65
T-BAT LD848
- SYSTEM DATA

  Number of modules 16
  Nominal capacity 85.1 kWh
  Max.output current 120 A
  Peak discharge current
  200 A, 10s
- GENERAL

  Nominal voltage 51.2 V
  Dimension (L x W x H) 645 x 150 x 430 mm
  Weight 48.5 kg
  Battery type Lithium iron phosphate
  Ingress protection IP65

Tải dữ liệu

Bảng dữ liệu
Hướng dẫn sử dụng
Hướng dẫn cài đặt nhanh

Tiếng Anh

Tiếng Việt

Tên tệp

Ngôn ngữ

Định dạng

Kích thước

Cập nhật gần nhất

Tải xuống
